The Orion CRX10D Refrigerated Air Dryer delivers clean, dry air with a capacity of 1.1 m³/min, operating at pressures from 0.2 to 0.98 MPa. Designed for industrial use, it features energy-saving R410A refrigeration and a robust stainless steel heat exchanger, ensuring optimal performance with inverter and oil-free compressors.
Efficient 1.1 m³/min air dryer for industrial compressed air systems with low pressure loss.
Benefits: Reduces moisture for improved air quality, Energy-efficient design lowers costs, Compatible with various compressor types.
Usage Tips: Install with Orion Clean Air Filters for best results; regular maintenance of the auto drain trap is recommended.
Support: Contact us for installation support or manuals.
The Orion CRX10D Refrigerated Air Dryer delivers clean, dry air with a capacity of 1.1 m³/min, operating at pressures from 0.2 to 0.98 MPa. Designed for industrial use, it features energy-saving R410A refrigeration and a robust stainless steel heat exchanger, ensuring optimal performance with inverter and oil-free compressors.
| Air Capacity | 1.1 m³/min |
|---|---|
| Pressure Range | 0.2–0.98 MPa |
| Inlet Air Temp | 10°C–80°C |
| Ambient Temp | 2°C–43°C |
| Dimensions | 820 x 240 x 610 mm |
| Weight | 35 kg |
| Power | 220V, 0.37 kW |
| Refrigerant | R410A |
